604GZM1-7045

The 604GZM Series is a general purpose gage pressure switch, DPDT with a stainless steel port. It is easily mounted to bulkheads, corrosion resistant and ideal for wet conditions rated to NEMA 4 and IP65. It is constructed with an integral terminal box and switch design and easy set point adjustment. It is also UL certified with high vibration and shock resistance utilizing Dual Snap® disc spring

Contact Us

The 604GZM Series is a general purpose gage pressure switch, DPDT with a stainless steel port. It is easily mounted to bulkheads, corrosion resistant and ideal for wet conditions rated to NEMA 4 and IP65. It is constructed with an integral terminal box and switch design and easy set point adjustment. It is also UL certified with high vibration and shock resistance utilizing Dual Snap® disc spring technology. Applications include nonhazardous environments such as:

• Power Generation

• Rail Car

• Fluid Management

• Manufacturing Process

• Utilities, Water Treatment and Waste

• Chemical Refining and Processing

• Heavy Vehicles

• Safety Systems


Why Choose Us

———

Profession

The company has a complete product line, including providing a wide range of industrial automation brand accessories

Experience

12 years of sales and distribution experience

Services

Focused on supplying products from world-renowned brands

Technical Support

We sell spare parts with one year warranty, which are rigorously tested and certified.

Environmental Approvals

IP65, NEMA 4, NEMA 13, NACE, RoHS

Industry

Industrial

Instrumentation

Pressure Switch

Environment

Non-Hazardous

Certification Agency Approvals

UL, CE, CRN, CCC

Operating Temperature Range

-40° to 186 °F

Process Connection Fitting Size

Female 1/2" NPT

Process Connection Material

Stainless Steel

Housing Enclosure

Aluminum

Electrical Connection

Female 3/4" NPT

Electrical Switch Type

DPDT

Voltage Electrical Rating VAC

0 to 250 VAC, 251 to 480 VAC

Amperes Electrical Rating

0.5 to 5 A

Fixed or Adjustable Set Point

Adjustable

Presetting

Factory Set, Not Factory Set

Tagging

Mylar, Stainless Steel

Accessories

Manifold

Increasing Pressure Range

1.2 to 16 PSIG, 8 to 75 PSIG, 20 to 150 PSIG, 50 to 375 PSIG, 330 to 1000 PSIG, 950 to 2300 PSIG

Decreasing Pressure Range

22 to 347 PSIG, 265 to 935 PSIG, 3 to 70 PSIG, 8 to 138 PSIG, 0.4 to 15.2 PSIG, 775 to 2125 PSIG

Pressure Type

Gage

Media

Oil Based, Non-Oil Based

Increasing Pressure Ranges

1.16 – 2.99 PSI, 3 – 180 PSI, 180.01 – 3400 PSI

Decreasing Pressure Ranges

0 – 1.15 PSI, 1.16 – 173 PSI, 173.01 – 3180 PSI

Maximum System Pressure

500, 3000

Maximum Proof Pressure

750, 5000

Process Connection Seal

O-Ring Sealed Diaphragm

Diaphragm

Polyimide

O-ring

Viton
